TDG-MT SERIES FIXED FRAME TRAILED TYPE DISC CULTIVATOR
TDG-MT SERIES FIXED FRAME TRAILED TYPE DISC CULTIVATOR

                 Ozdoken TDG series is produced from 250 cm to 400 cm working width and is suitable for tractors between 70-160 horsepower. TDG series, thanks to its independent disc structure, allows serial operation  All TDG series have conical bearing and dust seal, sliding battery as standart.


TRAILED TYPE

STANDART CAGE TYPE ROLLER

STANDART 510X4,0 MM DISC DIMENSION

OPTIONAL 560X4,5 MM DISC DIMENSION

Product Equipment
STANDART CAGE ROLLER STANDART CAGE ROLLER

CONICAL BEARING WITH GREASE POINT CONICAL BEARING WITH GREASE POINT

RUBBER DISC SUSPENSION RUBBER DISC SUSPENSION

On TDG series, each disc has individually rubber suspension.

STANDART BATTERY SLIDER STANDART BATTERY SLIDER

Technical Specifications
Model
# of Disc
Disc Dimension
Distance Between Discs
 Working Width (cm) Transport Width (cm) Tyre Size Minimum Weight (kg)
Power Requirement
TDG- MT20 20    510X4,0 / 560X4,5 24,5  250 280 10.0/75-15.3 1500 70-90 hp  52-67 kW
TDG- MT24 24   510X4,0 / 560X4,5 24,5  300 330 10.0/75-15.3 2000 90-120 hp 67-90 kW
TDG-MT28 28   510X4,0 / 560X4,5 24,5  350 380 10.0/75-15.3 2500 110-140 hp 82-105 kW
TDG-MT32 32   510X4,0 / 560X4,5 24,5  400 430 10.0/75-15.3 2060 130-160 hp 97-120 kW
